型号 |
适用链条直径 |
A |
B |
C |
D |
E |
F |
G |
自重 |
|
Art.NO |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
kg |
|
HDH6 |
6 |
9 |
48 |
21 |
7 |
50 |
12 |
20.5 |
0.09 |
|
HDH8 |
8 |
11 |
58 |
21 |
9 |
54 |
14 |
24.5 |
0.17 |
|
HDH10 |
10 |
14 |
74 |
27 |
12 |
68 |
18 |
31.5 |
0.39 |
|
HDH12 |
12 |
17.5 |
94 |
37 |
13.5 |
88 |
20 |
41 |
0.64 |
|
HDH14 |
14 |
20 |
106 |
41 |
16 |
98 |
28 |
45.5 |
1.11 |
|
HDH16 |
16 |
23 |
114 |
45 |
18 |
110 |
30 |
48.5 |
1.15 |
|
HDH18 |
18 |
25 |
124 |
48 |
20 |
120 |
34 |
52.5 |
2.01 |
|
HDH20 |
20 |
28 |
131 |
50 |
23 |
130 |
36 |
55 |
2.67 |
|
HDH22 |
22 |
30 |
138 |
53 |
25 |
140 |
41 |
57.5 |
3.58 |
|
HDH24 |
24 |
33 |
150 |
29 |
27 |
152 |
45 |
62.5 |
4.70 |
|
HDH26 |
26 |
37 |
166 |
63 |
30 |
51 |
47 |
70 |
5.76 |
|
HDH30 |
30 |
40 |
180 |
65 |
33 |
170 |
50 |
7605 |
6.84 |
|
HDH34 |
34 |
42 |
190 |
73 |
34 |
206 |
54 |
80 |
8.74 |
