代号 code |
重量/KG |
主要尺寸mm |
WLL/T |
B.L/T |
|||||
|
φ1 |
R |
D |
φ2 |
H |
E |
||||
|
8-YTQ081-6 |
0.5 |
22 |
110 |
10.5 |
35 |
22 |
28 |
1.2 |
4.8 |
|
8-YTQ081-7/8 |
0.8 |
25 |
134 |
12 |
46 |
24 |
34 |
2 |
8 |
|
8-YTQ081-10 |
1.5 |
32 |
170 |
15 |
55 |
28 |
45 |
3.2 |
12.8 |
|
8-YTQ081-13 |
3.2 |
40.5 |
206 |
20 |
69 |
40 |
54 |
5.4 |
21.6 |
|
8-YTQ081-16 |
6.1 |
56 |
249 |
22 |
84 |
51 |
63 |
8.2 |
32.8 |
|
8-YTQ081-20 |
7.5 |
64.5 |
273 |
27 |
100 |
56 |
81 |
12.5 |
50 |
|
8-YTQ081-22 |
13.4 |
70 |
320 |
30 |
99 |
47 |
82 |
15 |
60 |
|
8-YTQ081-26 |
18.5 |
80 |
362 |
34 |
110 |
75.5 |
114.5 |
21.5 |
82.8 |
|
8-YTQ081-32 |
44.5 |
105 |
472 |
45 |
147 |
96 |
168 |
31.5 |
126 |
